1PH8133-1DG00-0BA1 SIMOTICS M 20kW 96Nm 45A 2300rpm

SIMOTICS M compact asynchronous motor 2000 rpm 20 kW 96 Nm 45 A 350 V 2300 rpm 22.5 kW 93 Nm 44 A 400 V 2650 rpm 24 kW 86 Nm 41 A 456 V 2800 rpm 25 kW 85 Nm 41 A 480 V forced ventilation; direction of air flow DE--> NDE; IP55 degree of protection Incremental encoder 22-bit with commutation position (encoder IC22DQ) with DRIVE-CLiQ interface DESIGN IM B3 (IM V5, IM V6) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE: R/A, FLANGE ACCURACY: R TERMINAL BOX (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END
